The iTrans 2 infrared gas sensor employs an intelligent electronics platform to provide one or two points of detection from a single head for maximum flexibility, superior performance and lower installation costs. With the optional HART Communication Protocol, the iTrans 2 offers remote diagnostics, set-up or calibration by superimposing a high-frequency current across the industry standard 4-20mA analog line.

Specs

Key Specifications
Sensors Combustible Gases: Catalytic, Infrared. Toxic / Oxygen: Electrochemical, Infrared (CO2)
Display Dual-channel split-screen LED display (4 digit, 7 segment arrangement per channel) provides simultaneous display of one or two gases
Input voltage 12-28VDC operating range (24VDC typical)
Ingress Protection NEMA 4X, IP66
Response Time (catalytic methane) T50: < 10 seconds / T90: < 30 seconds
Humidity Range 10-90% RH (non-condensing), typical
Temperature Range (Sensor Specific) -40°C to +75°C (-40°F to +167°F)
